High reliability VPX& VNX Power Supply
The VPX series are compliant with VITA 62.0 and High Reiiability standard 181-86, 151A. The power supply mainly consists of EMI flter circuit inush limit circuit DC-DC converter, output fiter and contoling circuit. The VPX delivers up to 1000W and with flexible custom design output.
Application: Airborne, Missile borme, Vehicle, Radar, Weapons, Communication and Contolling System.
Special Features:
1. Input range: DC28V ( 18V-36V). AC115V+20% 400Hz. AC220V+20%50Hz. AC220V(85V-264V)50Hz meet almost all input voltage standards, provide models of mutiple input
2. Output voltage: +3.3V,+5.0V,+ 12V,+12V etc, provide several tens of custom design solutions
3. Output Output power up to 1000W, provide custom design solutions
4. Output control TTL level, filure alarm, voltage monitoring, redundancy. current share.
5.Input under voltage protection, output over current/short protection and over temperature protection
6. High efciencyup to 92%
7. Designed to meet VITA 62.0
8.rC bus protocol, JTAG (USB) connector, monitoring output voltage, output current and internal temperature
9. High rlibilit,, high performance on EMI
10. Size: Standard 3U, 6U. Provide custom design products
