CPCI Power Supply
The CPCI series are designed for a wide range of industrial & High Reiiability applications and compliant with High Reiiability standard 150A 2009. Dr.Power provides custom design for different requirement. The power supply mainly consits of regulation circuit, EMI filter circuit, inrush limit circuit, DC-DC converter, output filter and controlling circuit.
Application:  Harsh environment
Special Features:
1、Input voltage range: AC115V+20% 400Hz、 AC220V+20% 50Hz、 AC220V(85V-264V) 50Hz、DC28V(18V-36V)、DC48V(36V-72V);
2、Output voltage: +3.3V,+ 5.0V,+12V etc, provide custom design solutions
3、Output current: provide several tens of custom design solutions
4、Output control TTL level, and failure alarm, voltage monitoring, redundancy, current share.
5、High eficiency up to 92%
6、Meet PICMG2.11 R1.0 ( CompactPCI standard) ;
7、Input under voltage protection, output over current/short protetion and over temperature protection
